20A 12V/24V DC PWM Solar Charge Controller

A basic solar charge controller for permanent installations of lead acid or gel battery solar panel systems. It features a 3 stage charging sequence (boost, float and equalise). LEDs are provided to indicate working status – normal, fault, overload and low battery. Suitable for 12V or 24V systems, the charger automatically detects the connected battery voltage. Ideally suited to simple remote power systems such as water pumping stations, electric fences, remote lighting, marine applications etc.

Features

• Suits lead acid or gel battery systems
• Automatic fuse protection
• Battery overload & deep discharge protection
• Automatic 12/24V voltage selection
• Reverse polarity protection
• Short circuit protection
• Status LEDs
• Diode protection

Connection Diagram
